At a Glance

• USB format: FAT32; file in USB root
• Firmware must be named gor.tar (lowercase, exact)
• Platforms: PO and MOB are not interchangeable
• Process ≈ 3 minutes; screen may go black multiple times
• Remove USB only when prompted → power off & lock car 3 min → restart

Before You Start

1. Identify exact model/region from order or Settings → About (MCU/UI).
2. Download the official package for your unit.
3. Checksum verify the final file you will flash:

   Windows: certUtil -hashfile gor.tar SHA256
   macOS/Linux: shasum -a 256 gor.tar

4. Backup CAN protocol, themes, units, language.
5. Stable power >12.2V (maintainer ≥10A or engine on, ventilated area).

Prepare the USB Drive

1. Use quality USB 8–32GB (USB2/3).
2. Format to FAT32 (default allocation). If release notes require exFAT, follow that.
3. Copy the firmware to USB root. The final file to flash must be gor.tar.
4. Safely eject the USB.

Run the Update

1. 1Ignition to ACC/ON; wait until cluster fully boots.
2. 2Insert USB into the cluster harness service port (not media port).
3. 3Settings → System → Update → USB Update (some units auto-detect).
4. 4Confirm version → Start. Screen may black out / reboot several times.
5. 5On prompt → remove USB → power off & lock car 3 min → restart.

Post-Update Checklist

• Verify MCU/UI/OS in Settings → About.
• Restore language, units (°C/°F, km/h/mph), timezone, themes.
• Re-select CAN protocol (brand/model/year) if needed; test SWC, TPMS, indicators, icons.
• Short test drive to confirm speed/RPM/fuel or EV SOC, reverse overlay (if applicable).

Troubleshooting

Safety & Warranty Notes

• Use only Ikagoo-provided firmware for your model.
• Do not cut power or remove USB during flashing.
• Physical damage/water ingress/accidents are not covered.
• Keep photo/video records for support.

Related Resources

• Shop: LCD/Digital Instrument Clusters
• More install & update guides
• Warranty & Returns
• Official TikTok — Install Tutorials
• WhatsApp Support

FAQ

What file system should I use?

FAT32 by default; use exFAT only if the release notes require it.

Where do I place the firmware file?

USB root directory, named gor.tar exactly.

How long does the update take?

About 3–10 minutes. Some phases show no UI; do not power off.

Will I lose my settings?

Minor updates usually keep settings; major ones may reset to defaults.

Can I use any USB port?

No. Use the cluster’s service port, not the head unit media port.

How do I verify authenticity?

Compare published MD5/SHA256 with local hash via certUtil / shasum.

Can I downgrade?

Not recommended unless release notes explicitly allow it.

Black screen after reboot?

Keep power stable, retry with correct gor.tar, then contact support if needed.
